- Model : CPD-20
- Rated Lifting Capacity : 2000 kg
- Overall Length : Without fork: 2340 mm, With fork: 3450 mm
- Overall Width : Frame width: 1150 mm
- Overall Height : Height without lifting: 2150 mm, Overhead guardrail height: 2200 mm, Maximum height during operation: 4050 mm
- Wheel Base : 1510 mm
- Front Overhang : 480 mm
- Front Track : 960 mm
- Back Track : 960 mm
- Minimum Ground Clearance : Low end of mast: 80 mm, Middle of frame: 130 mm
- Maximum Lifting Height (without load) : 3000 mm
- Free Lifting Height : 3000 mm
- Mast Inclination : 6/12°
- Machine Weight (standard, without load) : 2700 kg
- Maximum Lifting Speed : Without load: 280 mm/s, With load: 180 mm/s
- Minimum Turning Radius : 2300 mm
- Maximum Moving Speed : Without load: 10.5 km/h, With full load: 10 km/h
- Maximum Climbing Grade (with full load) : 15%
- Load Center Distance : 500 mm
- Front Wheel : 650-10
- Back Wheel : 500-8
- Lifting Motor Power : 5 kW
- Drive Motor Power : 5 kW
- Turning Method : Hydraulic booster
- Voltage : 220V
- Rated Voltage : 60V
- Battery Capacity : 70 Ah
- Charging Time : 4 H
